RK-370 Carbon Brushed Micro DC motor

0) Model: RK-370CA
1) Output power: 0.3~24W;
2) Size: Φ24.4×30.8mm;
3) Voltage: DC 6V,12V;
4) No-load speed: 5400,6100 RPM;
5) No-load current: 0.028,0.06A;
6) Maximum efficiency torque: 25.77 G.CM;
7) Maximum efficiency power: 1.4W;
8).high quality;
9).Permanent Magnet brush motor;
10).ROHS

RK-370 Brushed micro dc motor

Main features:

RK-370 dc motor data examples:

Model	Voltage		No load		At maximum efficiency					Stall
	range	rated	speed	current	speed	current	torque	P	eff.	torque	current
	range	V	R/min	A	R/min	A	gf-cm	W	%	gf-cm	A
RF-370CA-12560	4.0-12.0	12	3,700	0.018	3,090	0.091	20.7	0.66	60.1	125	0.46
RF-370CA-15370	3.0-12.0	12	5,600	0.026	4,840	0.17	25.3	1.26	61.6	187	1.06
RF-370CA-12560	4.0-12.0	8	2,400	0.015	1,970	0.069	16	0.32	58.6	90	0.32
RF-370CB-81100	8.0-16.0	12	1,850	0.005	1,510	0.022	10.1	0.16	59.3	55	0.1
RF-370CH-22170	3.0-8.0	6	6,100	0.06	5,250	0.386	25.77	1.39	60.0	125	2.4
RF-370CH-17315	3.0-8.0	6	3,250	0.035	2,688	0.167	19.88	0.55	54.8	185	0.76
RF-370CH-15370	12.0-24.0	12	5,400	0.028	4,700	0.147	22.7	1.10	62.1	115	0.92
RF-370CH-11670	12.0-24.0	12	3,630	0.016	3,000	0.08	19.1	0.59	61.3	175	0.38
RK-370CA-95740	8.0-16.0	12	9,742	0.14	7,300	0.55	51.0	3.81	57.9	220	1.90
RK-370CA-15370	12.0-24.0	12	5,500	0.032	4,690	0.19	27.7	1.33	58.5	110	1.07
RK-370CA-10800	12.0-30.0	24	5,100	0.015	4,310	0.082	26.3	1.16	59.1	170	0.45
RK-370CA-81050	12.0-30.0	24	3,900	0.01	3,210	0.047	19.3	0.64	56.4	110	0.22
RK-370CH-96780	12.0-30.0	24	12,000	0.11	9,500	0.415	60.0	5.93	58.8	270	1.57

Dimensions and performance curves of RK-370(RF-370) dc motor for reference:

rf-370 micro brush dc electric motor

Download RK-370(RF-370 DC motor datasheet for clear view:

RK-370-datasheet.pdf

Notice: Data in this typical specification sheet are for other certain customers. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be customized to meet customer specific requirement.
